ATG5/APG5L Mouse Monoclonal Antibody

• Catalog Number: orb500007
• Category: Antibodies
• Description: ATG5/APG5L Mouse Monoclonal Antibody
• Species/Host: Mouse
• Clonality: Monoclonal
• Clone Number: 5D7
• Tested applications: ICC, IF, IHC-Fr, IHC-P, WB
• Predicted Reactivity: Mouse
• Reactivity: Human, Mouse, Rat
• Isotype: IgG
• Immunogen: Recombinant human ATG5 Protein full length
• Antibody Type: Primary Antibody
• Concentration: 1mg/ml
• Dilution range: WB=1:500-1000, IHC-P=1:100-500, IHC-F=1:100-500, ICC/IF=1:100, IF=1:100-500
• Form/Appearance: Liquid
• Conjugation: Unconjugated
• MW: 32 kDa
• Target: ATG5
• UniProt ID: Q9H1Y0
• Storage: Maintain refrigerated at 2-8°C for up to 2 weeks. For long term storage store at -20°C in small aliquots to prevent freeze-thaw cycles.
• Buffer/Preservatives: 0.01M TBS (pH7.4) with 1% rAlbumin, 0.02% Proclin300 and 50% Glycerol.
• Alternative names: ATG5; APG 5; APG 5L; APG5; APG5 autophagy 5 like;
• Note: For research use only
• Expiration Date: 12 months from date of receipt.

Hela cell, 4% Paraformaldehyde-fixed, Triton X-100 at room temperature for 20 min, Blocking buffer (normal goat serum) at 37°C for 20 min, Antibody incubation with (ATG5/APG5L) monoclonal Antibody, Unconjugated (orb500007) 1:100, 90 minutes at 37°C, followed by a conjugated Goat Anti-Mouse IgG antibody at 37°C for 90 minutes, DAPI (blue) was used to stain the cell nuclei.

Hela cell, 4% Paraformaldehyde-fixed, Triton X-100 at room temperature for 20 min, Blocking buffer (normal goat serum) at 37°C for 20 min, Antibody incubation with (ATG5/APG5L) polyclonal Antibody, Unconjugated (orb500007) 1:100, 90 minutes at 37°C, followed by a conjugated Goat Anti-Rabbit IgG antibody at 37°C for 90 minutes, DAPI (blue) was used to stain the cell nuclei.

Paraformaldehyde-fixed, paraffin embedded (Rat brain), Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min, Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes, Blocking buffer (normal goat serum) at 37°C for 30 min, Antibody incubation with (ATG5/APG5L) Monoclonal Antibody, Unconjugated (orb500007) at 1:800 overnight at 4°C, followed by operating according to SP Kit (Mouse) instructions and DAB staining.

Paraformaldehyde-fixed, paraffin embedded (rat stomach), Antigen retrieval by boiling in sodium citrate buffer (pH6.0) for 15 min, Block endogenous peroxidase by 3% hydrogen peroxide for 20 minutes, Blocking buffer (normal goat serum) at 37°C for 30 min, Antibody incubation with (ATG5) Monoclonal Antibody, Unconjugated (ascites of orb500007 5D7) at 1:2000 overnight at 4°C, followed by operating according to SP Kit (Mouse) instructions and DAB staining.

Sample: Lane 1: Human Hela cell lysates, Lane 2: Human Panc-1 cell lysates, Lane 3: Human U87MG cell lysates, Lane 4: Human MCF-7 cell lysates, Lane 5: Human K562 cell lysates, Lane 6: Human SH-SY5Y cell lysates, Primary: Anti-ATG5/APG5L (orb500007) at 1/1000 dilution, Secondary: IRDye800CW Goat Anti-Mouse IgG at 1/20000 dilution, Predicted band size: 32 kDa, Observed band size: 45 kDa.
